EDGE ALX Stacker
Are you ready for the big time? Then take a look at the EDGE® ALX Stacker trailers, designed for the motorsports professional and serious recreational enthusiast. Not only are EDGE® ALX Stackers large enough to haul multiple vehicles, but they have enough storage space for spare parts, tools and diagnostic equipment.
View availability near youFeatures
Polished Aluminum Front Corners
12v LED 9" x 7" Scene Lights (5000 Lumens)
Marine Battery with Vented Interior Floor Mount Battery Box
- 1-Piece Aluminum Roof
- Polished Aluminum Front Cap
- .040 White Bonded Aluminum Exterior (Smooth Appearance)
- 12K Hyd Landing Gear w/ Manual Override
- 3/4" PlexCore High Performance Decking
- 3/8" PlexCore High Performance Sidewall
- .030 White Aluminum Sidewall Covering
- Black Coin Rubber Floor Covering
- White Vinyl Ceiling Liner
- 24" ATP Stoneguard
- Steel Car Hoist System with 36" Extension
- 36" Aluminum Ramp Extension w/ Bumpers
- 5,000 lb. D-Rings with Welded Plate (4)
- 120/240v 50a Motorbase Receptacle with Lock Connect
- 16" OC Vertical Posts
- 3-Year Limited Warranty
- 16" OC Tube Roof Structure
- Spread Axle Design with Drop Skirting
- 8-Bolt 16" Radial Tires
- Silver Viper Aluminum Wheels
- 12v LED Clear Lens Exterior Lighting
- Bunk/Attic (6'6" from Floor to Under Side)
- Generator Compartment w/ 48" x 32" Access Door
- Air Compressor Prep Package
- 12v Main Shutoff Switch
- 12v LED 14" Flush Mount Ceiling Lights (8)
- 12v LED 6" Round Dome Lights (4)
- 16" OC Tube Crossmembers
- 2-5/16" 25,000 lb. Fixed Height Coupler with Steel Boot
Standard Features, Specifications and Available Options subject to change without notice.
Gallery
Specifications
| MODEL: | HARS85X24WR4 | HARS85X24WR5 | HARS85X28WR5 | HARS85X32WR5 |
|---|---|---|---|---|
| Body Length: | 24'0" | 24'0" | 28'0" | 32'0" |
| Body Width: | 8'4" | 8'4" | 8'4" | 8'4" |
| Overall Length: | 29'0" | 29'0" | 33'0" | 37'0" |
| Overall Width: | 8'6" | 8'6" | 8'6" | 8'6" |
| Overall Height: | 13'5" | 13'5" | 13'5" | 13'5" |
| Interior Length: | 23'8" | 23'8" | 27'8" | 31'8" |
| Interior Width: | 8'1" | 8'1" | 8'1" | 8'1" |
| Interior Height: | 11'3" | 11'3" | 11'3" | 11'3" |
| Width Between Wheel Boxes: | 81" | 81" | 81" | 81" |
| Platform Height: | 25" | 25" | 25" | 25" |
| Auto Lift Length: | 13'0" | 13'0" | 16'0" | 16'0" |
| Auto Lift Height: | 6'8" | 6'8" | 6'8" | 6'8" |
| Torflex® Suspension E-Z Lube® Axles Qty: | Triple | Triple | Triple | Triple |
| Electric Brakes with Breakaway Kit: | Electric Drum | Electric Drum | Electric Drum | Electric Drum |
| Radial Tire Size: | ST235/85R16 | ST235/85R16 | ST235/85R16 | ST235/85R16 |
| Tire Load Range: | E | E | E | E |
| Hitch Ball Size: | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" |
| Hitch to Top of Ball: | 23" | 23" | 23" | 23" |
| Hitch Weigh (% of Curb Weight): |
10% - 15% | 10% - 15% | 10% - 15% | 10% - 15% |
| GVWR: (Total Capacity Trailer + Cargo) |
18,000 lbs. | 21,000 lbs. | 21,000 lbs. | 21,000 lbs. |
| Curb Weight (Approximate): | 7,600 lbs. | 8,750 lbs. | 9,600 lbs. | 10,700 lbs. |
| Payload Capacity (Approximate): | 10,400 lbs. | 12,250 lbs. | 11,400 lbs. | 10,300 lbs. |
| Rear Door Opening (W x H): | 92" x 96" | 92" x 96" | 92" x 96" | 92" x 96" |
| Side Door Opening (W x H): | 48" x 72" | 48" x 72" | 60" x 78" | 60" x 78" |
| 12v Male Connection: | 7-Way | 7-Way | 7-Way | 7-Way |
| Tube Main Rails: | 2" x 8" | 2" x 8" | 2" x 8" | 2" x 8" |
Standard Features, Specifications and Available Options subject to change without notice.
Popular Options
First Aid Kit
Aluminum Ramp Hinge Cover
Gasoline Access Door
ATP Wheel Wells
Fabric Kickplate
Generator & Fuel Remote Controls
PitPal Foldable Table
Tinted Glass Windows
RTP Floor Covering
Winch
VIP Power Jack
ALX Stacker Workbench & Cabinet Package
Standard Features, Specifications and Available Options subject to change without notice.
